Maintenance
Do not use chemical clea ning agents; they may damage the probe. Avoid using chemicals that contain benzine, benzene,
toluene, xylene, acetone, or similar solvents.
Clean the exterior surfaces of the probe with a dry, lint-free cloth or a soft-bristle brush. If dirt remains, use a soft cloth or swab
dampened with a 75% isopropyl alcohol solution and rinse with deionized water. A swab is useful for cleaning narrow spaces on the
probe, use only enough solution to dampen the swa b or cloth. Do not use abrasive compounds o n any part of the probe.
Repairing the Probe
The subassemblies listed below can be replaced on the probe. The re placement procedures are on the following pages.
Replaceable component Procedures to use
Transformer Probe Head Disassembly, Transformer Replacement
Cable/Circuit Board Assembly Probe Head Disassembly, Cable/Circuit Board Assembly Replacement,
Compensation Box Replacement
Compensation Box Compensation Box Replacement
Switch Panel Compensation Box Replacement
TCP0030 C urren t Probe Instruction Manual 67
