Maintenance
Maintenance
This section contains maintenance information for your probe .
Troubleshooting
The TCP0030 current probe is designed to work with all TekVPI-interface oscilloscopes and adapters. The LEDs on the probe alert
you to error or status conditions affecting the probe. If the probe L EDs do not light as expected, or if some of the probe features do
not work properly, an error condition may exist. See the following table.
Table 7: Probe troubleshooting
Symptom
Possible cause
LEDs on the probe do not light. The oscilloscope channel may be bad:
Try another channe l or another oscilloscope. If the probe still does not work, th e probe
is defective, and must be returned to Tektronix for repair.
An error message displays on
the oscilloscope.
The message will describe the cause and solution. For example, if the D eg auss Needed
message appears, perform the degauss procedure.
Cleaning
Protect the probe from adverse weather conditions. The prob e is not waterproof.
CAUTION. To prevent damage to the probe, do not expose it to sprays, liquids, or solvents. Avoid getting moisture inside
the probe during exterior cleaning.
66 TCP0030 Current Probe Instruction Manual
