Specifications
Nominal Characteristics
Nominal characteristics describe gu aranteed traits, but the traits do not have tolerance limits.
Table 5: N om inal electrical characteristics
Characteristic Description
Input coupling
DC
Current ranges
5 A and 30 A
Termination
Terminate output into 1 M Ω
Compatibility Oscilloscopes equipped with the TekVPI interface
Certifications and Compliances
EC Declaration of Conformity - Low Voltage
Compliance was demonstrated to the following specifica tion as listed in the Official Jou rnal of the European Communities:
Low Voltage Directive 73/23/EEC, amended by 93/68/EEC.
EN 610 10-1: 2001. Safety requirements for electrical e quipment for measurement control a nd laboratory use.
EN 61010-2 -032:2 002. Particular requ irements for h andhe ld current clamps for electrical measurement and test equipment.
TCP0030 C urren t Probe Instruction Manual 47
