Maintenance
Reassembly
1. Before reassembling t he probe body, be sure to check:
a. That the gap between the stationary and moveable core pieces is clean. If necessary, use isopropyl alcohol or a similar
cleaning agent to clean the pieces.
b. That the contacts of the slide switch are clean, and if not, clean them.
c. If the plastic slide assembly requires lubrication. If so, apply silicone-based grease sp aringly to the parts.
2. Reassemble the probe body by following steps 1 through 8 o f the probe head disassembly procedure in reverse. (See
page 69 , Probe Head Disassembly.)
NOTE. Exercise care when fitting the slide back into the probe body; aligning the switch contacts requires pre cision.
If the slider does n ot work smoothly after tightening the two screws, loosen the screws slightly.
76 TCP0030 Current Probe Instruction Manual
