Specifications
Table 3: Environmental characteristics
Characteristic Description
Temperature
Operating: 0 to +50 °C (+32 to +122 °F)
Nonoperating: -40 to +75 °C (-40 to +167 °F)
Humidity
Operating: 5-95% RH, tested up to +30 °C (+86 °F)
5-85% RH, tested at +30 °C to +50 °C (+86 °F to +122 °F)
Nonoperating: 5-95% RH, tested up to +30 °C (+86 °F)
5-85% RH, tested at +30 °C to +75 °C (+86 °F to +167 °F)
Altitude
Operating: Up to 3000 meters (10,000 feet),
Nonoperating: Up to 12,192 meters (40,000 feet)
Table 4: Typical mechanical characteristics
Characteristic Description
Dimensions, compensation box
107mm×41mm×26mm(4.2in×1.6in×1.0in)
Dimensions, probe head
197 mm × 1.6 cm × 3.2 cm (7.77 in × 0.625 in × 1 .25 in)
Dimensions, cable length
2 m (79 in) (f rom the probe head to the compensation box)
Unit weight
1.550 g (3.44 lbs) (probe, accessories, and packa ging)
TCP0030 C urren t Probe Instruction Manual 45
