Tektronix TDS2000C series User Manual

Reference
Options Settings Comments
BW Limit
20 MHz
1
,Off
Limits the ban
dwidth to reduce display noise;
filters the signal to reduce noise and other
unwanted high frequency components
Volts/Div Coarse, Fine Selects the resolution of the Scale (Volts/Div)
knob
Coarse defines a 1-2-5 sequence. Fine
changes the resolution to s mall steps
between the
coarse settings
Probe
See the next
table
Push to adjust Probe options
Invert
On, Off Inverts (fl
ips) the waveform with respect to
the reference level
1
Effective bandwidth is 6 MHz with a P2220 probe set to 1X.
The option for volta
ge and current probes is different: Attenuation o r Scale.
Probe op tio ns Settings Comments
Probe ►Voltage
►Attenuation
1X, 10X, 20X, 50X, 100X,
500X, 1000X
Set to match the attenuation
factor of the voltage probe
to ensure correct vertical
readouts
Probe ►Current ► Scale 5 V/A, 1 V/A , 500 mV/A,
200 mV/A, 100 mV/A,
20 mV/A, 10 m V/A, 1 mV/A
Set to match the scale of
the current probe to ensure
correct vertical readouts
Back Returns to the previous
menu
Knobs
Vertical Position Knobs. Use the Vertical Position knobs to move the channel
waveformsupordownonthescreen.
Vertical Scale (volts/division) Knobs. Use the Vertical Scale knobs to control how
the oscilloscope amplifies or attenuates the source signal of channel waveforms.
WhenyouturnaVertic al Scale knob, the oscilloscope increases or decreases the
vertical size of the waveform on the screen.
Vertical Measurement Overrange (Clipping). Waveforms that extend beyond the
screen (overr ange) and display a ? in the measurement readout indicates an
invalid value. Adjust the vertical scaling to ensure the readout is valid.
Key Po ints
Ground Coupling. Use Ground coupling to display a zero-volt waveform.
Internally, the channel input is connected to a zero-volt reference level.
Fine Resolution. The vertical scale readout displays the actual volts/division
setting while in the fine resolution setting. Changing the setting to coarse does not
change the vertical scale until the Vertical Scale control is adjusted.
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual 105
