Specifications
1-4
TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
Table 1- 1: Oscilloscope general characteristics (Cont.)
Horizontal
Sample Rate Range TPS2012 and TPS2014 TPS2024
5S/sto1GS/s 5S/sto2GS/s
Waveform Interpolation (sin x)/x
Record Length 2500 samples for each channel
SEC/DIV Range TPS2012 and TPS2014 TPS2024
5ns/divto50s/div,ina
1, 2.5, 5 sequence
2.5 ns/div t o 50 s/div, in a 1, 2.5, 5 sequence
n Sample Rate and Delay
Time Accuracy
±50 ppm over any ≥1 ms time interval
Delta Time Measurement
Accuracy (Full Bandwidth)
Conditions Accuracy
Single-shot, sample
mode
±(1 sample interval + 100 ppm × reading + 0.6 ns)
>16 averages ±(1 sample interval + 100 ppm × reading + 0. 4 ns)
Sample interval = s/div ÷ 250
Position Range 2.5 ns/div t o 10 ns/div: (--4 div × s/div) to 20 ms
25 ns/div to 100 s/div: (--4 div × s/div) to 50 ms
250 s/divto10s/div:(--4div× s/div) to 50 s
25 s/div to 50s/div: (--4 div × s/div) to 250 s
Trigger
n Trigger Sensitivity,
Coupling Sensitivity
Edge Trigger Type
DC
CH1, CH2, CH3
1
, CH4
1
1 div from DC to 10 MHz,
1.5 div from 10 MH z to Full BW
EXT 1 V from 50 Hz to full BW
EXT/5 5 V from 50 Hz to full BW
EXT/10 10 V from 50Hz to full BW
Trigger Sensitivity, Edge Coupling Sensitivity
Trigger Type, typical
AC Same as DC-coupled limits from 50 Hz and above
NOISE REJ Reduces the DC-coupled trigger sensitivity by 2 times f or greater
than 10 mv/div to 5 V/div
HF REJ Same as the DC-coupled limit from DC to 7 kHz, attenuates
signals above 80 kHz
LF REJ Same as the DC-coupled limits for frequencies above 300 kHz,
attenuates signal s below 300 kHz
1
Available only on 4-channel oscilloscopes.
