Adjustment Procedures
TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
5-7
Table 5- 2: Adjustment steps (Cont.)
Step
Two-channel
models
InputSignal source settingSignal
Step
Four-channel
models
56 56 Sine Wave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH2
57 57 Sine Wave Generator, 50 Ohm 1 MHz, 100 mV
p-p
58 58 Sine Wave Generator, 50 Ohm 1MHz,1V
p-p
59 59 Sine Wave Generator, 50 Ohm 50 kHz, 1.2 V
p-p
60 60 Sine Wave Generator, 50 Ohm 20 MHz, 1.2 V
p-p
61 61
ne
e
ener
tor, 50
m
,30m
p-p
62 62 Sine Wave Generator, 50 Ohm BWL, 60 mV
p-p
63 63 Sine Wave Generator, 50 Ohm BWL, 120 mV
p-p
64 64 Sine Wave Generator, 50 Ohm BWL, 300 mV
p-p
65 65 Sine Wave Generator, 50 Ohm BWL, 600 mV
p-p
66 66 Sine Wave Generator, 50 Ohm BWL, 1.2 V
p-p
67 67 Sine Wave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
68 68 Sine Wave Generator, 50 Ohm 1MHz,2.5V
p-p
69 69 Sine Wave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
70 70 Sine Wave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
,
,
.
-
,
,
-
