Adjustment Procedures
5-8
TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
Table 5- 2: Adjustment steps (Cont.)
Step
Two-channel
models
InputSignal source settingSignal
Step
Four-channel
models
NA
73 Sine Wave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH3
74 Sine Wave Generator, 50 Ohm 1 MHz, 100 mV
p-p
75 Sine Wave Generator, 50 Ohm 1MHz,1V
p-p
76 Sine Wave Generator, 50 Ohm 50 kHz, 1.2 V
p-p
77 Sine Wave Generator, 50 Ohm 20 MHz, 1.2 V
p-p
78
ne
e
ener
tor, 50
m
,30m
p-p
79 Sine Wave Generator, 50 Ohm BWL, 60 mV
p-p
80 Sine Wave Generator, 50 Ohm BWL, 120 mV
p-p
81 Sine Wave Generator, 50 Ohm BWL, 300 mV
p-p
82 Sine Wave Generator, 50 Ohm BWL, 600 mV
p-p
83 Sine Wave Generator, 50 Ohm BWL, 1.2 V
p-p
84 Sine Wave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
85 Sine Wave Generator, 50 Ohm 1MHz,2.5V
p-p
86 Sine Wave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
87 Sine Wave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
,
,
.
-
,
,
-
90 Sine Wave Generator, 50 Ohm BWL, 1.6 V
p-p
91 Edge, 50 Ohm. Refer to Edge setup
diagram.
1 kHz, 0 to --800 mV, fast rising edge
