Adjustment Procedures
TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
5-9
Table 5- 2: Adjustment steps (Cont.)
Step
Two-channel
models
InputSignal source settingSignal
Step
Four-channel
models
NA
92 Sine Wave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH4
93 Sine Wave Generator, 50 Ohm 1 MHz, 100 mV
p-p
94 Sine Wave Generator, 50 Ohm 1MHz,1V
p-p
95 Sine Wave Generator, 50 Ohm 50 kHz, 1.2 V
p-p
96 Sine Wave Generator, 50 Ohm 20 MHz, 1.2 V
p-p
97
ne
e
ener
tor, 50
m
,30m
p-p
98 Sine Wave Generator, 50 Ohm BWL, 60 mV
p-p
99 Sine Wave Generator, 50 Ohm BWL, 120 mV
p-p
100 Sine Wave Generator, 50 Ohm BWL, 300 mV
p-p
101 Sine Wave Generator, 50 Ohm BWL, 600 mV
p-p
102 Sine Wave Generator, 50 Ohm BWL, 1.2 V
p-p
103 Sine Wave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
104 Sine Wave Generator, 50 Ohm 1MHz,2.5V
p-p
105 Sine Wave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
106 Sine Wave Generator, 50 Ohm 20 MHz, 2. 5 V
p-p
107 Sine
e Gener
tor, 50 Ohm B
L, 2.5
-
,
,
.
-
108 Sine
e Gener
tor, 50 Ohm B
L, 5
-
,
,
-
