Computer System Requirements

Operating System: Microsoft Windows XP or Microsoft Windows 7.

Network Connection: 10Mbps or 100Mbps, full-duplex TCP/IP connection. Static IP Address preferred.

Processor Speed: Intel Pentium Dual CPU 1.80GHz.

Memory: Minimum of 2.00GB recommended.
