Configuration
System Manager Multicast Address Field
The System Manager Multicast Address field displays the Multicast Address for TSM.
System Manager Incoming Port Field
The System Manager Incoming Port field displays TSM’s incoming port number.
System Manager Outgoing Port Field
The System Manager Outgoing Port field displays TSM’s outgoing port number.
System Manager TTL Field
The System Manger TTL field is used to set the number of routers the multicast packets are allowed to pass through before
being discarded.
The range for this field is, 1 to 6.
The default for this field is, 6.
MISC INFO
MAC Address Field
The MAC Address field displays the ADHB-4’s MAC address. This field is for information only and is not editable.
Serial Number Field
The Serial Number field displays the ADHB-4’s Serial Number. This field is for information only and is not editable.
NOTE: The serial number can also be found on the label attached to the bottom of the ADHB-4.
Kernel Version Field
The Kernel Version field displays the ADHB-4 Software Kernel version. This field is for information only and is not editable.
Submit Button
The Submit button is used to submit changes made to the Ethernet Setup window. Once clicked, the parameters are
temporarily saved.
NOTE: The Save Parameters button must be clicked to permanently save the new configuration to the unit.
To permanently save parameters, do the following:
1. From the left navigation pane, click Save Parameters.
The Save Parameters window opens.
2. Click Save Parameters.
The configuration is saved to the ADHB-4.
