19
CHAPTER 2
Installation
WARNING: Do not open the unit. No user-serviceable parts are contained within. Bosch cannot be responsible for
damage. If the unit is opened, the warranty can be voided. For troubleshooting steps contact the technical
support center. See “Phone Numbers” on page 2 for contact information.
Installation
REFERENCE: The installation process requires you to reference both this manual and the C-Soft Software Console
Administrator’s Guide (P/N LIT000082000) which is available on the CD that ships with the ADHB-4 or
can be downloaded at www.Telex.com/Downloads/.
To Install your ADHB-4:
Step 1 Determine where to mount your ADHB-4.
Step 2 Determine if an RHB is required for your system. See “Remote Headset Box” on page 73.
Step 3 Connect hardware to the ADHB-4. See “Connect ADHB-4 Hardware” on page 27.
Step 4 Install the current version of C-Soft. For more information. See the C-Soft Software Console
Administrator’s Guide (P/N LIT000082000).
Step 5 If using Windows 7 OS, install the ADHB-4 driver. See “Install the ADHB-4 Driver with Windows 7” on
page 28.
Step 6 Connect the ADHB-4 to power. “Apply Power to the ADHB-4” on page 34.
Step 7 Connect the ADHB-4 to the PC. “Connect the USB Cable” on page 34.
Step 8 If using Windows XP OS, install the ADHB-4 driver. See “Install the ADHB-4 Driver with Windows XP”
on page 30.
Step 9 Set up the ADHB-4 using the web browser configuration windows. See “Configuration” on page 35.
Step 10 Set up C-Soft parameters. See the C-Soft Software Console Administrator’s Guide
(P/N LIT000082000).
CAUTION: Do not apply power to the unit until step 6. Failure to heed this caution will result in damage to the unit. Bosch is
not responsible for damage caused when power is applied before the installation process is complete and the
warranty can be voided.
