43
Configuration
Headset Mic Slider
The Headset Mic slider is used to configure the input level for a headset mic.
The range for this field is -12dB to 10dB.
XLR Desk Mic Slider
The XLR Desk Mic slider is used to configure the input level for an XLR headset mic.
The range for this field is -12dB to 10dB.
NENA GAINS
NENA Input Slider
The NENA Input slider is used to configure the input level for a NENA phone.
The range for this field is -30dB to 9dB.
NENA Output Slider
The NENA Output slider is used to configure the output level for a NENA phone.
The range for this field is -30dB to 9dB.
RECORDER OUTPUT GAINS
Common Record Vol Slider
The Common Record Vol slider is used to configure the volume gain for the common recorder. The common recorder output
is a summation of any active audio in the dispatch position. Common audio sources include: Select, Unselect (optional),
microphone, NENA TX (included with microphone), and NENA RX.
The range for this field is -20dB to 9dB.
Unselect Record Vol Slider
The Unselect Record Vol slider is used to configure the volume gain for the Unselect recorder. This recorder output is
Unselect audio transmitted from C-Soft to the ADHB-4.
The range for this field is -20dB to 9dB.
NOTE: Unselect audio can be configured for inclusion in the common recorder output if desired. See “Common Record
Unsel Check Box” on page 52.
