Ethernet Setup Window
Unit IP Address Field
The Unit IP Address field is used to assign a unique static IP Address to the ADHB-4.
The default IP Address is, 192.168.1.150.
Subnet Mask Field
The Subnet Mask field is used to enter the Subnet Mask Address. The Subnet Mask Address is used to distinguish local
addresses from addresses that require the use of a gateway to reach. A subnet mask is required when configuring the system
for a static IP Address.
The default for this field is, 255.255.0.0.
Default Gateway Field
The Default Gateway field is used to enter the Gateway Address. The Gateway Address is the IP Address for the node used to
reach other networks. A Gateway Address is required when configuring the system for a static IP Address.
The default for this field is, 192.168.1.1.
DNS Address 1–3 Fields
The DNS Address 1–3 fields are used to enter the DNS (Domain Name System) Addresses. This Address points to the DNS
server on your network. See your network administrator for these values.
The default for this field is, 0.0.0.0.
To set up ADHB-4 Ethernet IP, do the following:
NOTE: Contact your network administrator for required values.
1. In the Unit IP Address field, enter the IP Address for the ADHB-4.
2. In the Subnet Mask field, enter the Subnet Mask for the network.
3. In the Default Gateway field, enter the Gateway IP Address of the network node.
4. In the DNS 1–3 fields, enter DNS Addresse(s).
5. Click Submit.
6. From the left navigation pane, click the Save Parameters link.
7. Click Save Parameters.
The configuration is saved to the ADHB-4.
TELEX SYSTEM MANAGER SETUP
System Manager Enable Check Box
The System Manager Enable check box is used to enable communication between the ADHB-4 and TSM (Telex System
Manager). TSM provides a centralized location to configure Telex Radio Dispatch solutions. The ADHB-4 firmware is
updated with TSM.
To enable communication between ADHB-4 and TSM, do the following:
> From the Ethernet Setup window, select the System Manager Enable check box.
Communication between the ADHB-4 and TSM is enabled.
REFERENCE: For more information, see the Telex System Manager Technical Manual (P/N LIT000259000), available for
download at www.telex.com./Downloads/.
