LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 148 of 149 2023-03-16
Not Subject to NDA
Revision Date Changes
Section 14.1:
Added LE910C1 NS Max antenna gain.
Added LE910C1 NS FCC ID & IC number.
1.02 2017-04-03 Section 14.1 – updated column “Band” to “Frequency Band” in Wireless notice
table
Section 8.4.1 - Added note regarding DTR
1.01 2017-02-16 Adding Section 14: FCC/ISED Regulatory notices
Changing Document History section from 14 to 15
1.0 2016-12-22 Section 1.5 - Updated “Related Documents” table
Section 5.3.4 – Added Figure for SHDN_N power down timing
Section 8.5.3 – Added clarification about VMMC
Section 9.7 - Added GNSS characteristics
0.6 2016-12-07 Remove all China variant related information
0.5 2016-12-02 Added section 9.2 to better describe SW_RDY signal
Minor modifications per typos and improved description
Renaming of SHDN_N pin
0.4 2016-11-30 Updated band support table
Updated WIFI application note doc info
Added note related to future compatibility related to few pins
Updated section 3.2 - Signals That Must Be Connected
Updated pinout and pin description
Updated pinout layout (Figure 2)
Remove HW RESET description section
Updated serial port 2 section
Updated SPI port section
Updated 1.8V pads pull info
Updated AUX UART section
Updated GPIO section
Updated mechanical drawing (Cosmetic)
0.3 2016-11-13 Added information for GPIO usage as Interrupt
Added clarification for AUX_UART location and backward compatibility
0.2 2016-09-05 Minor edits
0.1 2016-08-30 First Draft
