LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 147 of 149 2023-03-16
Not Subject to NDA
Revision Date Changes
Section 8.5.4 – Removed note related to WIFI_SDRST
Section 9.7 - Updated GNSS characteristics
1.12 2018-03-18 Replaced LE910C1 with LE910Cx throughout the document
Section 2.6.1 and Table 1 - Added LE910C1-EU and LE910C4-NF variants
Section 8.7 – Added notes related to GPIO pullups
Section 10.7.2 - Added clarification related to flux cleaning
1.11 2018-02-22 Section 5.3.2 – Updated section name
Section 5.4 – Added section for clarifying power down and power off procedures
Section 8.6.1 – Update for PCM slave mode
1.10 2017-12-27 General spelling and grammar edits throughout the document
Section 2.3 – Updated features list table.
Section 2.4 - Fixed typo in section and inside block diagram.
1.09 2017-12-07 Section 14.1 – Updated LE910C1 NA 850MHz Max antenna gain.
Section 6.2.2 – Corrected Class12 to Class10.
1.08 2017-11-14 Section 2.6.2 - Changed B41 to B41M
Section 2.7 – Renamed from Sensitivity to RF parameters and added TX output
power section (2.7.2)
Section 2.8 – Added note regarding label thickness
Section 3.1 - Removed duplication of description related to USB_VBUS.
Section 5.2 – Added clarification regarding ON_OFF.
Section 7.5 – Added note related to GPS port.
Section 8.1 – Added clarification regarding VBUS supply.
Section 8.1.1 – Added clarification regarding OTG.
Section 8.3.1 – Added clarification regarding ETH_INT_N pin.
1.07 2017-07-23 Adding a note for power supply section
1.06 2017-07-10 Renaming the product from LE910Cx to LE910C1
1.05 2017-06-18 Section 6.1 – Updated power consumption tables
1.04 2017-05-25 Section 14.1 – Added Labelling Requirements for the Host device
1.03 2017-04-23 Section 11.4:
Updated ESD values
Updated Reference document table
Section 8.3 - Updated Ethernet control interface information
Section 8.5.2 – Added note related to I2C
Section 2.6.2 – Updated table 4 with B25 information.
