Telit Wireless Solutions ME910G1 Design Guide

ME910G1 Hardware Design Guide
1VV0301593 Rev.12 Page 12 of 93 2021-09-24
Not Subject to NDA
Function
Features
Interfaces
• USB 2.0 HS (AT command
1
, FW upgrade and module diagnostic)
• USIF0 Main UART (AT command
1
and FW upgrade)
• USIF1 Auxiliary UART (AT Command
1
, AppZone diagnostic)
• 10 GPIOs
• Antenna port
Table 3: Functional features
1
Functionality depending on ports configuration
TX Output Power
ME910G1-W1
Band
Mode
3GPP Class
RF power (dBm)
Nominal*
B1, B2, B3, B4, B5, B8, B12, B13, B14, B18, B19,
B20, B25, B26, B27, B28, B66, B85, B8_39d
(LTE) CAT-M1
5
21
B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20,
B25, B26, B28, B66, B71, B85, B86, B8_39d
(LTE) CAT-NB2
5
21
Table 4: Transmission Output power
ME910G1-WW
Band
Mode
Class
RF power (dBm)
Nominal*
850/900MHz
GSM/GPRS
4
32.5
EGPRS
E2
27
1800/1900MHz
GSM/GPRS
1
29.5
EGPRS
E2
26
B1, B2, B3, B4, B5, B8, B12, B13, B18, B19,
B20, B25, B26, B27, B28, B66, B85, B8_39d
(LTE) CAT-M1
3
23
B1, B2, B3, B4, B5, B8, B12, B13, B18, B19,
B20, B25, B26, B28, B66, B85, B86, B8_39d
(LTE) CAT-NB2
3
23
B71
(LTE) CAT-NB2
5
21
Table 5: Transmission Output power ME910G1-WW
* Max output power tolerance range according to 3GPP TS 36.521-1 and 3GPP TS 51.010-1 or better
