ME910G1 Hardware Design Guide
1VV0301593 Rev.12 Page 13 of 93 2021-09-24
B1, B2, B3, B4, B5, B8, B12, B13, B18,
B19, B20, B25, B26, B27, B28, B66, B85
B1, B2, B3, B4, B5, B8, B12, B13, B18,
B19, B20, B25, B26, B28, B66, B85
Table 6: Transmission Output power ME910G1-WWV
* Max output power tolerance range according to 3GPP TS 36.521-1 and 3GPP TS 51.010-1 or better
RX Sensitivity
ME910G1-W1
REFsens (dBm)*
3GPP limit
