5. DIGITAL SECTION
ME910G1 has four main operation states:
• OFF state: Vbatt is applied and only RTC is running. Baseband is switched OFF and
the only change possible is the ON state.
• ON state: baseband is fully switched on and ME910G1 is ready to accept AT
commands. ME910G1 can be idle or connected.
• Sleep mode state: main baseband processor is intermittently switched ON and AT
commands can be processed with some latency. ME910G1 is idle with low current
consumption.
• Deep sleep mode state: PSM defined in 3GPP Release 12. Baseband is switched
OFF most of the time.
Logic Levels
Table 17: Logic levels Minimum and maximum
Table 18: Logic levels average
Parameter
Min
Max
ABSOLUTE MAXIMUM RATINGS – NOT FUNCTIONAL
Input level on any digital pin (CMOS 1.8) with respect to ground
-0.3V
2.1V
Operating Range - Interface levels (1.8V CMOS)
Input high level
1.5V
1.9V
Input low level
0V
0.35V
Output high level
1.6V
1.9V
Output low level
0V
0.2V
Parameter
Max
Current characteristics:
Output Current
1mA
Input Current
1uA
