Telit Wireless Solutions ME910G1 Design Guide

ME910G1 Hardware Design Guide
1VV0301593 Rev.12 Page 25 of 93 2021-09-24
Not Subject to NDA
Note: When turning on the modem, the voltage must be at least
VBATTmin.
Note: The HardwareUser Guide specifications must be recognized
and carefully implemented to use the module in its “Extended
Operating Voltage Range”.
Power Consumption
Idle Mode
Table 12: Idle and PSM Mode
1
PSM in between eDRX
Mode
Measure (Typical)
Mode Description
IDLE mode
CATM
(mA)
NBIoT
(mA)
2G
(mA)
AT+CFUN=1
9.5
9.2
9.0
Normal mode: full functionality of the module
AT+CFUN=4
7.5
Disabled TX and RX; module is not registered on the
network
AT+CFUN=5
1.20
0.95
-
Paging cycle #256 frames (2.56s DRx cycle)
0.60
0.60
-
81.92s eDRx cycle length (PTW=2.56s, DRX=1.28s)
0.18
1
0.18
1
-
327.68s eDRx cycle length (PTW=2.56s, DRX=1.28s)
0.10
1
0.10
1
-
655.36s eDRx cycle length (PTW=2.56s, DRX=1.28s)
0.05
1
0.05
1
-
1310.72s eDRx cycle length (PTW=2.56s, DRX=1.28s)
0.03
1
0.03
1
-
2621.44s eDRx cycle length (PTW=2.56s, DRX=1.28s)
-
-
0.90
Paging Multiframe 9
PSM mode
Typical (mA)
AT+CPSMS=1
3uA
No current source or sink by any connected pin
