ME910G1 Hardware Design Guide
1VV0301593 Rev.12 Page 53 of 93 2021-09-24
6. RF SECTION
Antenna Requirements
The antenna connection and the board layout design are the most important aspect of the
complete product design. It strongly affects the general performance of the product, so
read carefully and follow the requirements and the guidelines for a proper design.
The antenna and antenna transmission line on PCB for a Telit ME910G1 device shall fulfil
the following requirements:
Depending by frequency band(s) provided by the network operator, the
customer shall use the most suitable antenna for that/those band(s)
250 MHz in LTE Band 1
140 MHz in LTE Band 2, PCS1900
170 MHz in LTE Band 3, DCS1800
445 MHz in LTE Band 4
70 MHz in LTE Band 5, GSM850
80 MHz in LTE Band 8, GSM900
47 MHz in LTE Band 12
41 MHz in LTE Band 13
60 MHz in LTE Band 18
60 MHz in LTE Band 19
71 MHz in LTE Band 20
145 MHz in LTE Band 25
80 MHz in LTE Band 26
62 MHz in LTE Band 27
100 MHz in LTE Band 28
490 MHz in LTE Band 66
81 MHz in LTE Band 71
48 MHz in LTE Band 85
ME910G1-W1: > 24dBm Average power
ME910G1-WW: > 33dBm Average power
≤ 10:1 (limit to avoid permanent damage)
≤ 2:1 (limit to fulfill all regulatory requirements)
Table 28: ME910G1 Antenna and Antenna transmission line on PCB
