ME910G1 Hardware Design Guide

1VV0301593 Rev.12 Page 18 of 93 2021-09-24

Not Subject to NDA

Signal

I/O

Function

Type

Comment

DVI_TX

I/O

Digital Audio Interface (TX)

1.8V

DVI_CLK

I/O

Digital Audio Interface (CLK)

1.8V

SPI

D15

SPI_MOSI

I/O

SPI MOSI

CMOS

1.8V

E15

SPI_MISO

I/O

SPI_MISO

CMOS

1.8V

F15

SPI_CLK

I/O

SPI Clock

CMOS

1.8V

H14

SPI_CS

I/O

SPI Chip Select

CMOS

1.8V

DIGITAL IO

GPIO_01

I/O

GPIO_01 /STAT LED

CMOS

1.8V

STAT LED is

alternate function

internal PD (100K)

GPIO_02

I/O

GPIO_02

CMOS

1.8V

internal PD (100K)

C10

GPIO_03

I/O

GPIO_03

CMOS

1.8V

internal PD (100K)

C11

GPIO_04

I/O

GPIO_04

CMOS

1.8V

internal PD (100K)

B14

GPIO_05

I/O

GPIO_05

CMOS

1.8V

internal PD (100K)

C12

GPIO_06

I/O

GPIO_06

CMOS

1.8V

internal PD (100K)

C13

GPIO_07

I/O

GPIO_07

CMOS

1.8V

internal PD (100K)

K15

GPIO_08

I/O

GPIO_08

CMOS

1.8V

internal PD (100K)

L15

GPIO_09

I/O

GPIO_09

CMOS

1.8V

internal PD (100K)

G15

GPIO_10

I/O

GPIO_10

CMOS

1.8V

internal PD (100K)

ADC

ADC_IN

Analog Digital Converter input

RF SECTION

ANTENNA

I/O

LTE Antenna

(50 ohm)
