Tenda AP4 User Manual

80
Name
Description
AES, TKIP, and TKIP&AES values.

AES: It indicates the Advanced Encryption Standard.

TKIP: It indicates the Temporal Key Integrity Protocol. If TKIP is used, the maximum
wireless throughput of the AP is limited to 54 Mbps.

TKIP&AES: It indicates that both TKIP and AES encryption algorithms are
supported. Wireless clients can connect to the WiFi network corresponding to the
selected SSID using TKIP or AES.
Key
It specifies a pre-shared WPA key (WiFi password). It consists of 8 to 63 ASCII
characters or 8 to 64 hexadecimal characters.
Key Update Interval
It specifies interval at which a WPA key is updated. A shorter interval leads to higher
security. 0 indicates that no key update is performed.
Isolate Client
This parameter implements a function similar to the VLAN function for wired
networks. It isolates the wireless clients connected to the same WiFi network
corresponding to an SSID, so that the wireless clients can access only the wired
network connected to the device. Applying this function to hotspot setup at public
places such as hotels and airports helps increase network security.
Isolate SSID
It specifies whether to isolate the wireless clients connected to the AP with different
SSIDs.

Enable: It indicates that the wireless clients connected to the AP with different
SSID cannot communicate with each other. This improves wireless network
security.

Disable: It indicates that the wireless clients connected to the AP with different
SSIDs can communicate with each other.
Max. Number of Clients
This parameter specifies the maximum number of clients that can connect to the
WiFi network corresponding to an SSID. If the number is reached, the WiFi network
rejects new connection requests from clients. This limit helps balance load among
devices.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
