Tenda AP4 User Manual

133
Appendix
Default parameters
The default parameters are shown in the following table:
Parameters
AP4/AP5
Login
Login IP Address
192.168.0.254
Account
admin/admin
Quick Setup
Working Mode
AP mode
LAN Setup
IP Address Type
Static IP address
IP Address
192.168.0.254
Subnet Mask
255.255.255.0
DHCP Server
Enable
VLAN Settings
VLAN Settings
Disable
SSID
Support 2 WiFi networks at most.
The default SSID is Tenda_XXXXXX. XXXXXX is the last six
characters of the LAN MAC address with a range of XXXXXX
to XXXXXX + 1.
The first SSID is enabled and the other one is disabled.
Wireless > Basic
WiFi network
Enabled
Network mode
11b/g/n
LAN Rate
PoE/LAN Speed
Auto Negotiation
LAN Speed

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
