Tenda AP4 User Manual

91
6.3 Access control
6.3.1 Overview
The device allows you to set whitelist (allow to access the internet) or blacklist (disallow to access
the internet) based on wireless clients’ MAC addresses.
6.3.2 Configuring access control
Step 1 Log into the web UI of the device, and choose Wireless > Access Control.
Step 2 Select a SSID to which the rule applies.
Step 3 Enable the Access Control function.
Step 4 Select a MAC address filter mode, Disallow or Allow.
Step 5 Add the client to be controlled.
− Manual enter: Enter the MAC address of the client in the MAC Address input box, and
click Add.
− Quick add: Click Add online devices to add all connected clients to the access control
list quickly.
Step 6 Click Save.
----End
Access control list
Used to
disable/enable the
rule
Used to delete
the rule

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
