Tenda AP4 User Manual

92
Parameters description
Name
Description
SSID
It specifies the WiFi networks supported by the device.
Access Control
It specifies whether to enable the function.
Mode
It specifies the mode for filtering MAC addresses.

Allow: It indicates that only the wireless clients on the access control list can
connect to the selected WiFi network of the device.

Disallow: It indicates that only the wireless clients on the access control list cannot
connect to the selected WiFi network of the device.
6.3.3 Example of configuring access control
Networking requirement
A WiFi network named Connect Me has been set up in a residential community. Only the
community members are allowed to connect to the WiFi network.
Solution
The Access Control function is recommended. Assume that the community members’ wireless
devices whose MAC addresses are C8:3A:35:00:00:01, C8:3A:35:00:00:02, and C8:3A:35:00:00:03.
Configuration procedure
Step 1 Log into the web UI of the device, and choose Wireless > Access Control.
Step 2 Select Connect Me from the SSID drop-down list.
Step 3 Enable the Access Control function.
Step 4 Set the Mode to Allow.
Step 5 Enter the MAC addresses one by one and click Add.
Step 6 Click Save.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
