Tenda AP4 User Manual

132
8.4 System log
To access the page, choose Tools > System Log. The maximum of 300 items can be saved. After the
total log items exceed the maximum number, the previous logs will be cleared.
The logs of the device record various events that occur and the operations that users perform after
the device starts. In case of a system fault, you can refer to the logs during troubleshooting.
To ensure that the logs are recorded correctly, verify the system time of the device. You can correct
the system time of the device by choosing Tools > Date & Time.
To view the latest logs of the device, click Refresh. To clear the existing logs, click Clear.
 When the device reboots, the previous logs are cleared.
 The device reboots when one of the following situations occurs: the device is powered on after a
power failure, the VLAN function is configured, the firmware is upgraded, the configuration of the
device is backed up or restored or the factory settings are restored.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
