Tenda AP4 User Manual

81
WEP
Parameters description
Name
Description
Authentication Type
It specifies the authentication type for the WEP security mode. The options include
Open and Shared. The options share the same encryption process.

Open: It specifies that authentication is not required and data exchanged is
encrypted using WEP. In this case, a wireless client can connect to the WiFi network
corresponding to the selected SSID without being authenticated, and the data
exchanged between the client and the network is encrypted in WEP security mode.

Shared: It specifies that a shared key is used for authentication and data exchanged
is encrypted using WEP. In this case, a wireless client must use a preset WEP key to
connect to the WiFi network corresponding to the selected SSID. The wireless client
can be connected to the WiFi network only if they use the same WEP key.
Default Key
It specifies the WEP key for the Open or Shared encryption type.
For example, if Default Key is set to Security Key 2, a wireless client can connect to the
WiFi network corresponding to the selected SSID only with the password specified by
Security Key 2.
Key 1/2/3/4
Enter WEP key. You can enter four keys, but only the key specified in the Default Key
takes effect.
ASCII
It indicates that a key selected for the Open or Shared authentication type contains
hexadecimal characters.
5 or 13 ASCII characters are allowed in the key.
Hex
It indicates that a key selected for the Open or Shared authentication type contains
hexadecimal characters.
10 or 26 hexadecimal characters (range: 0-9, a-f, and A-F) are allowed in the key.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
