Tenda AP4 User Manual

82
WPA-PSK, WPA2-PSK, and Mixed WPA/WPA2-PSK
Parameters description
Name
Description
Security Mode
It indicates the personal or pre-shared key security mode, including WPA-PSK,
WPA2-PSK, and Mixed WPA/WPA2-PSK.

WPA-PSK: It indicates that the WiFi network corresponding to the selected SSID is
encrypted using WPA-PSK.

WPA2-PSK: It indicates that the WiFi network corresponding to the selected SSID
is encrypted using WPA2-PSK.

Mixed WPA/WPA2-PSK: It indicates that wireless clients can connect to the WiFi
network corresponding to the selected SSID using either WPA-PSK or WPA2-PSK.
Encryption Algorithm
It specifies the encryption algorithm corresponding to the selected security mode. If
Security Mode is set to WPA-PSK, this parameter has the AES and TKIP values. If
Security Mode is set to WPA2-PSK or Mixed WPA/WPA2-PSK, this parameter has the
AES, TKIP, and TKIP&AES values.

AES: It indicates the Advanced Encryption Standard.

TKIP: It indicates the Temporal Key Integrity Protocol. If TKIP is used, the maximum
wireless throughput of the AP is limited to 54 Mbps.

TKIP&AES: It indicates that both TKIP and AES encryption algorithms are
supported. Wireless clients can connect to the WiFi network corresponding to the
selected SSID using TKIP or AES.
Key
It specifies a pre-shared WPA key. A WPA key can contain 8 to 63 ASCII characters or
8 to 64 hexadecimal characters.
Key Update Interval
It specifies the automatic update interval of a WPA key for data encryption. A
shorter interval results in higher data security.
0 indicates that a WAP key is not updated.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
