2-9
2
Ratings and Specifications
Switch-disconnectors for DC600V-1000V
Frame size (A)
Type
Number of poles
■Ratings
Rated current, A
Rated insulation voltage〔
U
i
〕 V
Rated operational voltage V DC
Rated short time withstand current, kA
Rated impulse withstand voltage 〔
U
imp
〕 kV
■Performance
Utilization category ①⑲ DC
JIS C 8201-3 IEC 60947-3
■External dimensions, mm
a
b
c
d
Weight (' marked standard type) kg
■Connections and Mountings
Front-connected (FC) Terminal screws
With extension bars
Rear-connected (RC) Flat bar studs
Plug-in (PM)
For switchboards
For distribution boards
Draw-out type (DR)
TemPlug70 (PG)
TemPlug45B (PG4)
DIN rail mount
Clip-in chassis mount
■Accessories (optional) Symbol
Auxiliary switch ＡＸ
Alarm switch ＡＬ
Shunt trips ＳＨ
Undervoltage trips ＵＶ
Motor operator ＭＣ
External operating
Breaker-mounted ＨＢ
handle
Door-mounted (variable depth)
ＨＰ
Toggle extension ＨＡ
Mechanical interlock Slide type ＭＳ
Rear-connected type ＭＢ
Link type ＭＬ
Wire type ＭＷ
Toggle holder ＨＨ
Toggle lock ＨＬ
Terminal cover For front-connected ＣＦ
For rear-connected and plug-in ＣＲ
Interpole barrier ＢＡ
Terminal block for lead ＴＦ
Door flange ＤＦ
■Standard specifications
Colourofcover
Trip button (Colour)
Handle position indication (ON: Red, OFF: Green)
Suitability for isolation
Reverse connection
800
PVS800-NNH
4
630
800
1150
1000
10（0.3sec.）
8
DC-22A
280
273
103
145
11.5
―
'
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
●
―
―
―
―
●
●
●
●⑩
●
―
Grey
Yes (Red)
Yes
Yes
Yes
400
PVS400-NNH
4
400
1150
1000
5（0.3sec.）
8
DC-22A
185
260
103
145
5.6
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●
●⑨
●
―
Grey
Yes (Red)
Yes
Yes
Yes
400
PVS400-NNL
34
400
800 1150
750 800
5（0.3sec.）
8
DC-22A
140 185
260
103
145
4.25.6
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●
●⑨
●
―
Grey
Yes (Red)
Yes
Yes
Yes
800
PVS800-NNL
34
630
800
800 1150
750 800
10（0.3sec.）
8
DC-22A
210 280
273
103
145
8.511.5
―
'
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
●
―
―
―
―
●
●
●
●⑳ ●⑩
●
―
Grey
Yes (Red)
Yes
Yes
Yes
Notes:
' : Standard. This configuration used unless otherwise specified. ○ : Optional standard. Specify when ordering. ● : “yes” or “available”. ― : “no” or “not available”.
① : Connect 4poles in series.
⑨ : For front connection, both line and load side interpole barriers are supplied as standard. For rear connection, line side interpole barriers are supplied as standard.
⑩
: For front connection, 5pcs line side interpole barriers and 3pcs load side interpole barriers are supplied as standard. For rear connection, 5pcs line side interpole barriers are
supplied as standard.
⑲
: The time constant (L/R) of the circuit should be less than 2.0ms nearby rated current.
⑳
: For front connection, 4pcs line side interpole barriers and 2pcs load side interpole barriers are supplied as standard. For rear connection, 4pcs line side interpole barriers are
supplied as standard.
