TERASAKI TemBreak 2 - Pvs800-Ndl 3 P

4-18
Insulation distance DC750V-1000V
Front-connected
Rear-connected
513
105
E
F
D
C
210
C
AB 273
330
G G
B 273
C 210
C
105
F
ED
A
513
330
G G
Insulating plate
(supplied as standard)
Mounting plate
Ionised gas area
Insulating plate
(supplied as standard)
Mounting plate
Ionised gas area
Interpole barrier
Insulating plate
Interpole barrier
Insulating plate
Type Connection
PVS800-NDL3P
Front-connected
Rear-connected
160
Not supplied Supplied as standard
PVS800-NDL 3P
Minimum insulation distance (mm) Insulating plate
A B C D E F
Front panel side Mounting plate side
80 80 80 140 160
G
60
