TERASAKI TemBreak 2 - Toggle Holder (HH) and Toggle Lock (HL)

Red Red
Padlock
Up to three padlocks can be used
⎞
⎠
⎞
⎠
Red
ø5 – ø8
Padlock
Up to three padlocks can be used
⎞
⎠
⎞
⎠
Green
ø8 or less
Length to
the lever tip
Toggle holder (HH): Make sure
the lock lever of the toggle holder
is in the UNLOCK position, fit the
toggle holder onto the toggle and
swing the lock lever to the LOCK
position. The toggle is now locked
on or off.
Toggle lock (HL): Padlock the
toggle in the ON or OFF position.
Padlock
Up to three padlocks can be used
Lock lever
⎞
⎠
⎞
⎠
Fig. 1
Fig. 4
Fig. 3
Fig. 2
O
N
O N
OF
F
ø5
5-27
5
Accessories
Typeofbreaker
Toggleholder
Figure
Togglelock
Figure
S160-SD, S160-GD, S160-SDN,
PVE160-SDL
T2HH25L
4
T2HL25L
1
S250-SD, S250-GD, S250-SDN,
PVS160-SDL, PVS250-SDL,
PVS160-SNL, PVS250-SNL,
PVS160-SDH, PVS250-SDH,
PVS160-SNH, PVS250-SNH,
PVS160-GDH, PVS250-GDH
T2HH25L
4
T2HL25L
1
S400-ND,
PVS400-NDL, PVS400-NNL,
PVS400-NDH, PVS400-NNH,
S800-ND, S1000-ND,
PVS800-NDL, PVS800-NNL, PVS800-NDH
PVS800-GDH, PVS800-NNH
T2HL40
①
2
T2HL40
2
XS1250ND, XS1600ND
XKC9 3（R=86） XKC93（R=86）
XS2000ND, XS2500ND, XS3200ND
XKC10 3（R=94） XKC10 3（R=94）
Ordercodes OrdercodesMarkingcodes Markingcodes
T2HH25LT2HL25L
T2HH25LT2HL25L
T2HL40 T2HL40
XKC9 XKC9
XKC10 XKC10
3. Toggle holder (HH) and toggle lock (HL)
Toggle holders/toggle locks
Notes: 1. Same as toggle lock.
Toggle holder (HH)
Simply fitting the toggle holder onto the
breaker toggle disables breaker operation
without using padlocks.
Toggle lock (HL)
The toggle lock is a tool that locks the breaker on or off. When an overcurrent occurs, the
breaker will trip even if the breaker toggle is locked in the ON position.
(Use commercially available padlocks).
