TERASAKI TemBreak 2 - Switch-Disconnectors for DC600 V-1000 V

2-8
Switch-disconnectors for DC600V-1000V
Frame size (A)
Type
Number of poles
■Ratings
Rated current, A
Rated insulation voltage〔
U
i
〕 V
Rated operational voltage V DC
Rated short time withstand current, kA
Rated impulse withstand voltage 〔
U
imp
〕 kV
■Performance
Utilization category ①⑲ DC
JIS C 8201-3 IEC 60947-3
■External dimensions, mm
a
b
c
d
Weight (' marked standard type) kg
■Connections and Mountings
Front-connected (FC) Terminal screws
With extension bars
Rear-connected (RC) Flat bar studs
Plug-in (PM) For switchboards
For distribution boards
Draw-out type (DR)
TemPlug70 (PG)
TemPlug45B (PG4)
DIN rail mount
Clip-in chassis mount
■Accessories (optional) Symbol
Auxiliary switch ＡＸ
Alarm switch ＡＬ
Shunt trips ＳＨ
Undervoltage trips ＵＶ
Motor operator ＭＣ
External operating Breaker-mounted ＨＢ
handle Door-mounted (variable depth) ＨＰ
Toggle extension ＨＡ
Mechanical interlock Slide type ＭＳ
Rear-connected type ＭＢ
Link type ＭＬ
Wire type ＭＷ
Toggle holder ＨＨ
Toggle lock ＨＬ
Terminal cover For front-connected ＣＦ
For rear-connected and plug-in ＣＲ
Interpole barrier ＢＡ
Terminal block for lead ＴＦ
Door flange ＤＦ
■Standard specifications
Colourofcover
Trip button (Colour)
Handle position indication (ON: Red, OFF: Green)
Suitability for isolation
Reverse connection
250
S250-SDN
3
250
800
600
3（0.3sec.）
8
DC-22A
105
165＋55 ⑰
68
95
1.5
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●⑫
●⑫
●⑬
●
●
Grey
Yes (Red)
Yes
Yes
Yes
160
PVS160-SNL
4
160
800
800
3（0.3sec.）
8
DC-22A
140
165＋55×2 ⑰
68
95
1.9
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●
●
●
●
●
Grey
Yes (Red)
Yes
Yes
Yes
160
S160-SDN
3
160
690
600
2（0.3sec.）
8
DC-22A
75
130＋50 ⑰
68
95
0.8
'
○（BAR）
○
―
―
―
―
―
○⑪
―
●
●
●
●
―
●
●
―
―
―
―
―
●
●
●⑫
●⑫
●⑬
●
●
Grey
Yes (Red)
Yes
Yes
Yes
160
PVS160-SNH
4
160
1000
1000
3（0.3sec.）
8
DC-22A
140
165＋55×2 ⑰
68
95
1.9
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●⑧
●⑧
―
●
●
Grey
Yes (Red)
Yes
Yes
Yes
250
PVS250-SNL
34
250
800
750 800
3（0.3sec.）
8
DC-22A
105 140
165＋55×2 ⑰
68
95
1.51.9
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●⑧
●⑧
―
●
●
Grey
Yes (Red)
Yes
Yes
Yes
250
PVS250-SNH
4
250
1000
1000
3（0.3sec.）
8
DC-22A
140
165＋55×2 ⑰
68
95
1.9
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●⑧
●⑧
―
●
●
Grey
Yes (Red)
Yes
Yes
Yes
a
b
c
d
Notes:
' : Standard. This configuration used unless otherwise specified. ○ : Optional standard. Specify when ordering. ● : “yes” or “available”. ― : “no” or “not available”.
① : Connect 3poles or 4poles in series.
⑧ : Two terminal covers are supplied as standard. Be sure to install the terminal covers on Line side (ON side) and Load side (OFF side).
⑪
: Provided with DIN rail adaptor.
⑫
: Be sure to install the terminal covers on Line side (ON side) that is supplied as standard.
⑬
: Possible to fit on load side (option).
⑰
: ＋ means the dimension of the terminal cover. See outline dimensions for details.
⑲
: The time constant (L/R) of the circuit should be less than 2.0ms nearby rated current.
InteriorExterior
