TERASAKI TemBreak 2 - Accessories 1-1; Internally Mounted Accessories; Connection Diagrams and Terminal Numbers

5-2
Internally mounted accessories
1. Connection diagrams and terminal numbers
D1 D2
Ｕ１Ｕ２
12/AXb1 14/AXa1
11/AXc1
12/AXb1 14/AXa1
11/AXc1
22/AXb2 24/AXa2
21/AXc2
12/AXb1 14/AXa1
11/AXc1
22/AXb2 24/AXa2
21/AXc2
32/AXb3 34/AXa3
31/AXc3
42/AXb4 44/AXa4
41/AXc4
AXb1 AXa1
AXc1
AXb2 AXa2
AXc2
AXb3 AXa3
AXc3
AXb4 AXa4
AXc4
AXb5 AXa5
AXc5
AXb6 AXa6
AXc6
92/ALb1 94/ALa1
TRIP
91/ALc1
92/ALb1 94/ALa1
TRIP
91/ALc1
02/ALb2 04/ALa2
TRIP
01/ALc2
ALb1 ALa1
TRIP
ALc1
C1 C2
Ｓ２Ｓ１
〜
（−）
〜
（＋）
Applicable to MCCB type of “XS”. Shunt
trips are fitted with anti-burn switches.
Applicable to TemBreak2 breakers. Shunt
trips are continuous rating without anti-burn
switches.
Ex. 1pc Aux. Switch installed.
Ex. 2pcs Aux. Switch installed.
Ex. 4pcs Aux. Switch installed.
Ex. 6pcs Aux. Switch installed.
Thisisfor MCCB type of “XS”.
Ex. 1pc Alarm switch for MCCB type of
“XS”.
Ex. 1pc Alarm switch installed.
Ex. 2pcs Alarm switch installed.
＊Specialapplication.
Applicable to Tem Breakers2.
Applicable to XS1250ND and XS1600ND.
Accessory
Combination symbol Connection diagram and terminal No.
Remarks
Shunt trip device
(SH)
Auxiliary switch
(AX)
Alarm switch
(AL)
Undervoltage
trip device
(UV)
• Without anti-burn switch
• With anti-burn switch
For DC
