TERASAKI TemBreak 2 - Pvs160-Sdl 3 P; Pvs250-Sdl 3 P, Pvs250-Snl 3 P; Pvs160-Sdl 3 P, Pvs250-Sdl 3 P, Pvs250-Snl 3 P

4-9
4
Mounting and Connection
5
5
B 165 B
A 105 70
70
A
5
5
B 165 B
A 105
A
Terminal cover
Terminal cover
Insulating plate
(supplied as standard)
Mounting plate
Insulating plate
(supplied as standard)
Mounting plate
Insulating plate
(supplied as standard)
Mounting plate
Terminal cover
Terminal cover
Insulating plate
(supplied as standard)
Mounting plate
Type Connection
PVS160-SDL 3P
PVS250-SDL 3P
PVS250-SNL 3P
Front-connected
Rear-connected
50
Minimum insulation distance (mm) Insulating plate
A B
Terminal cover
65
2pcs are supplied for line
and load side as standard.
Insulating plate
2pcs of 115mm×137.5mm
are supplied as standard.
PVS160-SDL 3P, PVS250-SDL 3P, PVS250-SNL 3P
Front-connected
Rear-connected
