TERASAKI TemBreak 2 - Moulded Case Circuit Breakers for DC750 V-1000 V

2-5
Moulded Case Circuit Breakers for DC750V-1000V
2
Ratings and Specifications
Frame size (A)
Type
Number of poles
■Ratings
Rated current, A
Calibrated at 45°C
Rated insulation voltage〔
U
i
〕 V
Rated impulse withstand voltage 〔
U
imp
〕 kV
■Rated breaking capacity, kA
JIS C 8201-2-1 Ann.1 Ann.2 DC 1000V
IEC 60947-2 I
cu
/I
cs
①② 750V
■External dimensions, mm
a
b
c
d
Weight (' marked standard type) kg
■Connections and Mountings
Front-connected (FC) Terminal screws
With extension bars
Rear-connected(RC) Flat bar studs
Plug-in (PM) For switchboards
For distribution boards
Draw-out type (DR)
TemPlug70 (PG)
TemPlug45B (PG4)
DIN rail mount
Clip-in chassis mount
■Accessories (optional) Symbol
Auxiliary switch ＡＸ
Alarm switch ＡＬ
Shunt trips ＳＨ
Undervoltage trips ＵＶ
Motor operator ＭＣ
External operating Breaker-mounted ＨＢ
handle Door-mounted (variable depth) ＨＰ
Toggle extension ＨＡ
Mechanical interlock Slide type ＭＳ
Rear-connected type ＭＢ
Link type ＭＬ
Wire type ＭＷ
Toggle holder ＨＨ
Toggle lock ＨＬ
Terminal cover For front-connected ＣＦ
For rear-connected and plug-in ＣＲ
Interpole barrier ＢＡ
Terminal block for lead ＴＦ
Door flange ＤＦ
■Standard specifications
Overcurrent trip mechanism
Colourofcover
Trip button (Colour)
Handle position indication (ON: Red, OFF: Green)
Suitability for isolation
Reverse connection
160
PVS160-SDL
3
50 (32-50)
63 (40-63)
100 (63-100)
125 (80-125)
160 (100-160)
800
8
―
10/5
105
165＋55×2 ⑰
68
95
1.5
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●⑧
●⑧
―
●
●
Adj. thermal,
fixed magnetic
Grey
Yes (Red)
Yes
Yes
Yes
160
PVS160-SDH
4
50 (32-50)
63 (40-63)
100 (63-100)
125 (80-125)
160 (100-160)
1000
8
5/5
―
140
165＋55×2 ⑰
68
95
1.9
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●⑧
●⑧
―
●
●
Adj. thermal,
fixed magnetic
Grey
Yes (Red)
Yes
Yes
Yes
160
PVS160-GDH
4
50 (32-50)
63 (40-63)
100 (63-100)
125 (80-125)
160 (100-160)
1000
8
10/5
―
140
165＋55×2 ⑰
68
95
1.9
'
○（BAR）
○
―
―
―
―
―
―
―
●
●
●
●
●
●
●
―
―
―
―
―
●
●
●⑧
●⑧
―
●
●
Adj. thermal,
fixed magnetic
Grey
Yes (Red)
Yes
Yes
Yes
160
PVE160-SDL
3
25 (16-25)
32 (20-32)
40 (25-40)
63 (40-63)
80 (50-80)
100 (63-100)
125 (80-125)
160 (100-160)
800
8
―
3/3
75
130＋50×2 ⑰
68
95
0.8
'
○（ BAR）
○
―
―
―
―
―
―
―
●
●
●
●
―
●
●
―
―
―
―
―
●
●
●⑧
●⑧
―
●
●
Adj. thermal,
fixed magnetic
Grey
Yes (Red)
Yes
Yes
Yes
a
b
c
d
Notes:
' : Standard. This configuration used unless otherwise specified. ○ : Optional standard. Specify when ordering. ● : “yes” or “available”. ― : “no” or “not available”.
① : Connect 3poles or 4poles in series.
②
: The time constant (L/R) of the circuit should be,
less than 2.0ms nearby rated current
less than 5ms for short circuit ≦ 10KA
less than 10ms for short circuit ≦ 20KA
less than 15ms for short circuit ＞ 20KA
⑧
: Two terminal covers are supplied as standard. Be sure to install the terminal covers on Line side (ON side) and Load side (OFF side).
⑰
: ＋ means the dimension of the terminal cover. See outline dimensions for details.
InteriorExterior
