TERASAKI TemBreak 2 - Pvs160-Snl 4 P, Pvs250-Snl 4 P

4-10
Insulation distance DC750V-1000V
B 165 B
A 140 68
68
A
B 165 B
A 140
A
Terminal cover
Terminal cover
Mounting plate
Mounting plate
Terminal cover
Terminal cover
Mounting plate
Mounting plate
Type Connection
PVS160-SNL 4P
PVS250-SNL 4P
Front-connected
Rear-connected
50
Minimum insulation distance (mm)
Terminal cover
A B
65
2pcs are supplied for line and load side as standard.
PVS160-SNL 4P, PVS250-SNL 4P
Front-connected
Rear-connected
