TERASAKI TemBreak 2 - Pvs160-Snh 4 P, Pvs250-Snh 4 P

4-13
4
Mounting and Connection
13
13
B 165 B
A 140 70
70
A
13
13
B 165 B
A 140
A
Terminal cover
Terminal cover
Insulating plate
(supplied as standard)
Mounting plate
Insulating plate
(supplied as standard)
Mounting plate
Insulating plate
(supplied as standard)
Mounting plate
Terminal cover
Terminal cover
Insulating plate
(supplied as standard)
Mounting plate
PVS160-SNH 4P, PVS250-SNH 4P
Front-connected
Rear-connected
Type Connection
PVS160-SNH 4P
PVS250-SNH 4P
Front-connected
Rear-connected
30
Minimum insulation distance (mm) Insulating plate
A B
Terminal cover
65
2pcs are supplied for line
and load side as standard.
Insulating plate
2pcs of 166mm×137.5mm
are supplied as standard.
