Externally mounted accessories
4. Terminal covers
Plug-in mounted version
This version can be mounted simply
by being plugged in the breaker body.
Screw-mounted version
The terminal covers are mounted to
the breakers using tapping screws.
■ To be stated when ordering
• Please state the order codes on the next page if ordering separately from the breaker.
A
B
C
D
ø4
Hole for Megger
measurement
(at each terminal)
M3.5
Mounting
screw
ø4
Hole for Megger
measurement
C
D
A
B
B’
ø4
Hole for Megger
measurement
(at each terminal)
Fig.2
Fig.1
(2)
CR for rAear-connected and plug-in breakers
