November 2021
Table of Contents
x Scissor Lifts Part No. 1305686GT
Annual Maintenance Procedures .................................................................. 51
A-1 Check the Drive Hub Oil Level and Fastener Torque .................................. 51
A-2 Test the Function Pump - GS-69 BE and GS-69 DC .................................. 52
A-3 Test the Oscillate Axle - GS-90 .................................................................. 53
A-4 Test the Down Limit Switch Descent Delay -
GS-69, GS-84 and GS-90 (if equipped)..................................................... 56
A-5 Test the Platform Overload Pressure Transducer and
Platform Height Sensor ............................................................................. 57
A-6 Test the Platform Overload System -
GS-30m, GS-30, GS-32m, GS-32, GS-46, GS-55 ..................................... 63
A-7 Test the Platform Overload System - GS-69 (if equipped) .......................... 65
A-8 Check the Steer Yoke King Pin Fastener Torque ....................................... 67
Programmed Maintenance Procedures......................................................... 68
P0-1 Inspect the Engine Air Filter - GS-69 RT .................................................. 68
P0-2 Grease the Steer Yokes - GS-30m, GS-30, GS-32, GS-46, GS-55 ........... 69
P0-3 Replace the Drive Hub Oil - GS-30, GS-32m, GS-32, GS-46, GS-55 ........ 69
P0-4 Deutz Engine Maintenance – Under 1000 Hours ...................................... 70
P0-5 Ford Engine Maintenance – Under 1000 Hours ........................................ 71
P0-6 Kohler Engine Maintenance – Under 1000 Hours ..................................... 72
P0-7 Kubota Engine Maintenance – Under 1000 Hours .................................... 73
P0-8 Perkins Engine Maintenance – Under 1000 Hours ................................... 74
P0-9 GM Engine Maintenance – Under 1000 Hours ......................................... 75
P1-1 Perform Engine Maintenance – 1000 Hours ............................................. 76
P1-2 Replace the Drive Hub Oil - GS-69, GS-84, GS-90 ................................... 77
P2-1 Perform Engine Maintenance – 2000 Hours ............................................. 77
P2-2 Replace the Hydraulic Filters ................................................................... 78
P2-3 Check the Free-wheel Configuration - GS-84 and GS-90 ......................... 80
P2-4 Check the Scissor Arm Wear Pads (and Slider Blocks, if equipped) ......... 81
P2-5 Grease the Steer Axle Wheel Bearings - GS-69 BE and GS-69 DC .......... 84
P2-6 Test or Replace the Hydraulic Oil ............................................................. 86
P3-1 Perform Engine Maintenance – 3000 Hours ............................................. 87
P5-1 Perform Engine Maintenance – 5000 Hours ............................................. 88
P6-1 Perform Engine Maintenance – 6000 Hours ............................................. 88
