Terex Genie GS-1330m Maintenance Manual

Maintenance Manual November 2021
Torque Specifications
4 Scissor Lifts Part No. 1305686GT
Tires and Wheels
Torque values are listed as lubricated unless
otherwise noted. Lug nuts must be coated with a
mineral based lubricant when removed and
replaced on the machine.
Model
GS-
1330m
GS-
1432m / 1932m
GS-1932m Lite / 1932m XH
Castle nut torque
150 ft-
lbs
203 Nm
Model
GS-1530 / 1532
GS-1930 / 1932 / 1932 XH
Castle nut torque
225 ft-
lbs
305 Nm
Model
Models with
electric
drive
GS-2032 / 2632 / 3232
GS-
2046 / 2646 / 3246 / 4046
GS-
2646 XH / 3246 XH
GS-
4655
Hex head cap screw
80 ft-
lbs
108 Nm
Model
Models with
hydraulic drive
GS-2032 / 2632
Castle nut torque
225 ft-
lbs
305 Nm
Model
GS-2669 / 3369 / 4069 RT
Castle nut torque
(steer end)
225 ft-
lbs
305 Nm
Lug nut torque
(steer end)
68 ft-
lbs
92 Nm
Lug nut torque
(non
-steer end)
130 ft-
lbs
176 Nm
Model
GS-
2669 / 3369 / 4069
(DC and BE models)
Castle nut torque
(steer end)
150 ft-
lbs
203 Nm
Lug nut
torque
(steer end)
68 ft-
lbs
92 Nm
Lug nut torque
(non
-steer end)
130 ft-
lbs
176 Nm
Model
GS-
3384
GS-
3390 / 4390 / 5390
Lug nut torque
94 ft-
lbs
127 Nm
Tire pressure
high flotation
38 p
si
2,6 b
ar
