Terex Genie GS-1330m Maintenance Manual

November 2021 Maintenance Manual
Hydraulic Specifications
Part No. 1305686GT Scissor Lifts 13
Hydraulic and Drive Hub Fluid Capacities
Model Drive hubs Hydraulic tank
Hydraulic system
(including tank)
GS
-1330m X 1.06 gallons
4 liters
1.5 gallons
5,68 liters
GS
-1432m / 1932m / 1932m Lite / 1932m XH 10 fl oz
300 cc
1.06 gallons
4 liters
1.5 gallons
5,68 liters
GS
-1530 / 1532 / 1930 / 1932 / 1932 XH
Models with hydraulic drive
X
3.4 gallons
12,9 liters
3.8 gallons
14,2 liters
GS-1530 / 1532 / 1930 / 1932 / 1932 XH
Models with electric drive
16.9 fl oz
500 cc
1 gallons
3,8 liters
1.46 gallons
5,5 liters
GS
-2032 / 2632
Models with hydraulic drive
X
3.4 gallons
12,9 liters
4.5 gallons
17 liters
GS
-2032 / 2632 / 3232 / 2046 / 2646
GS
-2646 XH / 3246 XH
Models with electric drive
10 fl oz
300 cc
4 gallons
15,1 liters
6.13 gallons
23,2 liters
GS
-4046
10 fl oz
300 cc
4.9 gallons
18,5 liters
7.84 gallons
29,7 liters
GS
-4655 10 fl oz
300 cc
5.9 gallons
22,4 liters
7.94 gallons
30 liters
GS
-2669, GS-3369, GS-4069
(all models)
24.5 fl oz
725 cc
16.5 gallons
62,5 liters
18 gallons
68,1 liters
GS
-3384 26 fl oz
769 cc
30 gallons
114 liters
37.5 gallons
142 liters
GS
-3390
26 fl oz
769 cc
30 gallons
114 liters
37.5 gallons
142 liters
GS-4390
26 fl oz
769 cc
30 gallons
114 liters
38.25 gallons
145 liters
GS
-5390
26 fl oz
769 cc
30 gallons
114 liters
38.75 gallons
147 liters
