Terex Genie GS-1330m Maintenance Manual

November 2021 Maintenance Manual
Hydraulic Specifications
Part No. 1305686GT Scissor Lifts 11
Hydraulic Relief Valve Pressure
Manifold Relief Valve Pressure / Bar
Model
System
relief
Lift relief Steer relief
Outrigger
relief
Oscillate
relief
Traction
Manifold
Hot oil relief
GS
-1330m 2250 psi
155 bar
X 1600 psi
110 bar
X X X
GS
-1432m
1800 psi
124 bar
X X X X X
GS-1932m
GS
-1932m Lite
GS
-1932m XH
2400 psi
165 bar
X X X X X
GS
-1530 / 1532
GS
-1930 / 1932 / 1932 XH
Models with hydraulic drive
3700 psi
255 bar
3700 psi
255 bar
1500 psi
103 bar
X X X
GS
-1530 / 1532
Models with electric drive
2700 psi
186 bar
X X X X X
GS-1930 / 1932 / 1932 XH
Models with electric drive
3500 psi
241 bar
X X X X X
GS
-2032 / 2632
Models with hydraulic drive
3700 psi
255 bar
3700 psi
255 bar
1500 psi
103 bar
X X X
GS
-2032
Models with electric drive
2400 psi
165 bar
X X X X X
GS-2632
Models with electric drive
2100 psi
145 bar
X X X X X
GS
-3232 2300 psi
159 bar
X X 3500 psi
241 bar
X X
GS
-2046
2900 psi
200 bar
X X X X X
GS
-2646 / 2646 XH 2800 psi
193 bar
X X X X X
GS
-3246 / 3246 XH
2600 psi
179 bar
X X X X X
GS
-4046 2350 psi
162 bar
X X X X X
GS
-4655
2900 psi
200 bar
X X X X X
