Maintenance Manual November 2021
Programmed Maintenance Procedures
84 Scissor Lifts Part No. 1305686GT
GS-3384, GS-3390, GS-4390, GS-5390:
1 Measure the thickness of each chassis wear
pad at the steer end of the machine.
Result: The measurement is 5/16 inch / 8 mm
or more. Proceed to step 2.
Result: The measurement is less than
5/16 inch / 8 mm. Replace both wear pads.
2 Measure the thickness of each chassis wear
pad at the non-steer end of the machine.
Result: The measurement is 5/16 inch / 8 mm
or more. Proceed to step 3.
Result: The measurement is less than
5/16 inch / 8 mm. Replace both wear pads.
3 Measure the thickness of each platform
scissor arm wear pad at the steer end of the
machine.
Result: The measurement is 5/16 inch / 8 mm
or more. Proceed to step 4.
Result: The measurement is less than
5/16 inch / 8 mm. Replace both wear pads.
4 Measure the thickness of each platform
scissor arm wear pad at the non-steer end of
the machine.
Result: The measurement is 5/16 inch / 8 mm
or more.
Result: The measurement is less than
5/16 inch / 8 mm. Replace both wear pads.
P2-5
Grease the Steer Axle Wheel
Bearings - GS-69 BE, GS-69 DC
Genie requires that this procedure be performed
every 2000 hours.
Perform this procedure more often if dusty
conditions exist.
Maintaining the steer axle wheel bearings is
essential for safe machine operation and service
life. Operating the machine with loose or worn
wheel bearings may cause an unsafe operating
condition and continued use may result in
component damage. Extremely wet or dirty
conditions or regular steam cleaning and pressure
washing of the machine may require that this
procedure be performed more often.
1 Loosen the wheel lug nuts. Do not remove
them.
2 Block the non-steer wheels, then center a
lifting jack under the steer axle.
3 Raise the machine 6 inches / 15 cm and place
blocks under the drive chassis for support.
4 Remove the lug nuts. Remove the tire and
wheel assembly.
To Next Page
