Terex Genie GS-1330m Maintenance Manual

November 2021 Maintenance Manual
Battery Specifications
Part No. 1305686GT Scissor Lifts 5
GS-1330m
(standard)
Voltage
12V DC
Group
24
Type
24TMX
Quantity
2
Battery capacity, maximum
85AH
Reserve capacity @ 25A rate
140 minutes
GS-1330m
(optional)
Voltage
12V DC
Group
24
Type
DC85-12
Quantity
2
Battery capacity, maximum
85AH
Reserve capacity @ 25A rate
145 minutes
GS-1432m / 1932m
GS-1932m Lite / 1932m XH
(standard)
Voltage
12V DC
Group
24
Type
27TMH
Quantity
2
Battery capacity, maximum
115AH
Reserve capacity @ 25A rate
131 minutes
GS
-1432m / 1932m
GS-1932m Lite / 1932m XH
(optional)
Voltage
12V DC
Group
24
Type
EV31A-B
Quantity
2
Battery capacity, maximum
115AH
Reserve capacity @ 25A rate
minutes178
GS
-1530 / 1532
GS
-1930 / 1932 / 1932 XH
GS
-2032 / 2632
Models with hydraulic drive
(standard)
Voltage
6V DC
Group
GC2
Type
T-105
Quantity
4
Battery capacity, maximum
C20 = 225AH
Reserve capacity @ 25A rate
447 minutes
GS
-1530 / 1532
GS
-1930 / 1932 / 1932 XH
GS
-2032 / 2632
Models with hydraulic drive
(optional)
Voltage
6V DC
Group
GC2
Type
6V-AGM
Quantity
4
Battery capacity, maximum
200AH
Reserve capacity @ 25A rate
380 m
inutes
GS-1530 / 1532
GS
-1930 / 1932 / 1932 XH
GS
-2032 / 2632 / 3232
GS
-2046 / 2646 / 3246
GS
-2646 XH / 3246 XH
Models with electric drive
(standard)
Voltage
6V DC
Group
GC2
Type
T-605
Quantity
4
Battery capacity, maximum
C20 = 210AH
Reserve capacity @ 25A rate
383 minutes
Note: When upgrading from standard to AGM
batteries the machine software must be configured
for the proper battery type. Refer to Repair
Procedure, Machine Setup in the appropriate
Service and Repair Manual.
