Maintenance Manual November 2021
Quarterly Maintenance Procedures
42 Scissor Lifts Part No. 1305686GT
All other engine models:
Low rpm idle adjustment:
1 Loosen the lock nut on the low idle
adjustment screw.
2 Turn the adjustment screw clockwise to
increase low rpm or counterclockwise to
decrease low rpm.
3 Tighten the lock nut.
High rpm idle adjustment:
1 Loosen the lock nut on the high idle
adjustment nut.
2 Turn the high idle adjustment nut
counterclockwise to increase the rpm or
clockwise to decrease the rpm.
3 Tighten the lock nut.
Kubota D1105-E3B, D1105-E4B
1 high idle solenoid
2 low idle adjustment screw
3 lock nut
4 high idle adjustment nut
Deutz D2011L03i
1 high idle solenoid
2 high idle adjustment nut
3 lock nut
4 low idle adjustment screw
Perkins 403D-11
1 high idle solenoid
2 high idle adjustment nut
3 low idle adjustment screw
