This lift cannot be made
Example
Hook & Ball 239 lbs.
Slings 300 lbs.
Hook Block 750 lbs.
Object Lifted 2350 lbs.
Total Load Lifted 3749 lbs.
ON TIRES
On tires operation, particularly pick and carry, must be done in a slow, smooth
manner over level terrain that will support the crane, with the loads close to the
ground and the boom as low as possible to avoid the load swinging
unintentionally, causing injury or tip over. Do not pick and carry with the jib since
the load is further extended from the machine and the jib can be easily damaged
Operating Instructions
106 P/N 12261-319 REVISED: August 2012
