The maximum boom length shown on the On Tire chart is the maximum boom length that
can be used at the radius shown. This is done to limit the boom height when working on
tires. Do not exceed the maximum boom length for the given radius.
“Stationary” means that the crane cannot be moved when loaded to the levels shown in the
on tire load chart.
Ensure that the tires are inflated as shown in the recommended tire pressure
chart. Refer to procedure for tire inflation in Tire Maintenance Section.
“Creep” means the crane can be moved at a maximum speed of one (1) MPH for a
distance of 200 feet and then a 30 minute waiting period is necessary to cool the tires.
Overheating will greatly reduce the life of the tires.
Never move the crane carrying a load with the boom in any position except
straight over the front.
107P/N 12261-319 REVISED: August 2012
