HYDRAULIC PULLER-TENSIONER PT1250
Manual: MI-PT1250-050-01-IT Date: 06.11.2017 Author: AT Page: 58 of 69
- Machine like a PULLER: With the joystick of the MASTER machine (pos.5 p.9) it is possible to set the
recovery speed on all machines, while via the joystick of the SLAVE machines (pos.5 p.9) you can
make a small adjustment on the recovery speed of the single circuit, depending on the value set on the
master.
In this way, the operator can manually adjust the height of the wire or wire according to the line and the
various stretching operations that are being carried out.
Set pull force on
SLAVE machine
± XX KN
on MASTER
MACHINE
Set pull force in
all machine
XX KN
Set speed value on
the SLAVE machine
± XX Km/h
on MASTER
MACHINE
Set speed value in
all machine
XX Km/h
